9650-BINOCULAR RESEARCH MICROSCOPE

• This microscope offers viewing delight to the user.
• The design offer stain free observation and no back ache while working for longer duration.
• It consist of heavy aluminum base with electrical fitting inside and an inclined metal stand.
• Packed in shock proof thermocole box outer thick wooden box with instruction manual and vinyl Cover.

Technical Specification:

Magnification                   :      25X & 1000X

Head                                  :      Binocular head has adjustable inter papillary distance adjustment and diopter adjustment on the left tube.

Eye Piece                          :      Paired Huygenian 5X & WF 10X

Achromatic Objectives  :      5X & 10X & 40X & 100X Oil (SL,Par-Focal)

Nose Piece                       :      Ball bearing type quadruple nose piece is provided for precise movement of objectives.

Focusing System            :      Separate knobs for coarse and fine motion are provided on the body & the slow motion is drum type

Mechanical Stage           :      Large stage is fitted with a coxial-mechanical stage fo easy manipulation of Slids 45 inclined

                                                  binocular head to the stand by means of clamping screws.

Illumination                   :      Illumination by 6v-20w halogen lamp with on/off switch and intensity control

                                                  knob.Abbe type condenser having glass of 1.25 Numerical aperture with

                                                  iris diaphragm and swing out filter holder is provided.
