- Micron Pathological Inclined Monocular Microscope Model KG-7A Exel Economy is the newly introduced design for Medical colleges.
- Professionals & Laboratory use with the full features of the advanced research type Pathological Microscope.
- It has a very modern look & yet at a very affordable price that will surprise the most demanding users.
Standard Objectives: DIN
All the objectives are parcentered and parfocal minimize focusing procedures.
Features:
- Mechanical tube length 160 mm.
- 45º inclined with 360 degree rotatable binocular head.
- Co-axial built in Mechanical stage 125 x 150 mm with fine vernier graduation, designed with convenient coaxial adjustment on ball bearing guide ways for smooth slide manipulation through 50 x 70 mm.
- Dust proof quadruple/quintruple ball bearing revolving nose piece with positive click stops.
- Co-axial coarse & fine focusing adjustment knobs.. Fine motion, graduated to .002 mm.
- Substage Abbe type N.A. 1.25 condenser focusable with rack & pinion, continuously variable iris diaphragm with built in swing out filter holder.
- Steple Grey, chemical resistant, back-on finish.
- Exclusive preset focus lock prevents damage to valuable slides and objectives.
- Heavy rectangular sturdy base, with built-in illumination 6V – 20W halogen lamp.
- Complete parts of the microscope are pressure Die-casted.
- With dust cover packed in styrofoam packing
