9600-SINGLE NOSE MICROSCOPE

Technical Specification:

Body                  :    Monocular tube of mechanical length 160mm , inclinble upto 90 degrees. Triple revolving nosepiece with positive centring & click stops.

Stage                  :       Fixed Square Stage size 85×85 mm wit stage clips.

Focusing          :     Coarse type sensitive focusing using diagonally cut rack and pinion arrangement.

Illumination  :     Plano- Concave mirror mounted on gamble mount.

Eyepiece          :   Huygenian 10x.

Objectives      :   Achromatic 4X ,10X and 40XSL or only with Achromatic 10X.

Box                   :   Supplied in thermocol packing.
