TECHNICAL SPECIFICATION
- GENERAL PARAMETERS pH, mV and Temperature
- DISPLAY 7- segment bright Red LED Display (3 for Temperature and 4 pH/mV)
- KEY BOARD 6 Keys, soft touch membrane type
- POWER SUPPLY 230 + 10% VAC, 50Hz.
- pH RANGE 0.00 to 14.00 pH
- RESOLUTION 0.01 pH
- RELATIVE STABILITY 0.02 pH/Hour
- ACCURACY + 0.01 Ph + I Digit
- TEMPERATURE COMPENSATION 0 – 100ºC
- CALIBRATION Auto (2 or 3-point)
- AUTO BUFFER RECOGNITION 4.00, 7.00 & 9.20pH
- ACCEPTABLE ELECTRODE SLOPE 70% TO 130%
- mV RANGE 0 to + 1999 mV
- RESOLUTION I mV
- RELATIVE ACCURACY + I mV + I digit
- TEMPERATURE RANGE 0 – 100ºC
- RESOLUTION 0.1 ºC
- ACCURACY + 0.1 ºC
- SENSOR Semi – conductor (LM35) Type
- DIMENSIONS 275 X 182 X 85mm
- WEIGHT 3.5 Kg. (Approx.)
Standard Accessories – 1010
- Combined pH Electrode 1 No.
- Temperature Probe 1 No.
- Dust Cover 1 No.
- Instruction Manual 1 No.
- Electrode Stand 1 No.
- Buffer Tablets 4& 7pH 2 Nos. each
- Main Lead 1 No.
