10740-Flame Photometer- Microprocessor

TECHNICAL SPECIFICATIONS

• RANGE

1. Na: 0.1 to 100
2. K : 0.1 to 100
3. Ca: 15 to 100
4. Li: 0.5 to 100

• SENSITIVITY 1 ppm
• ACCURACY + 1% up to 40 ppm, + 2% above 40 ppm
• READOUT                    5 digit seven segment bright red LED display
• FLAME SYSTEM LPG & Dry Oil Free Air
• DETECTOR Photodiode
• CALIBRATION 3 point calibration
• POWER         230V + 10% AC, 50Hz.
• WEIGHT (Approx.)
• AIR SUPPLY :  By Oil Free Mini Compressor Unit With Pressure Regulator
• COMBUSTION GAS LPG
• ATOMISER Axial flow type
• BURNER Stainless Steel
• IGNITION SYSTEM Auto Ignition

SALIENT FEATURES:

    *  100 Open Tests

    * 40 x 4 line LCD Display

    * Graphical Thermal Printer

    * 28 Quick Access Test Keys

    * 18 ul Flowcell Volume

    * Peltier Controlled Thermostats

    * User Friendly Software

    * Auto lamp Shut Off

    * Programmable Air Gap Aspiration

    * Repeat Measurement of Sample in Flow cell

APPLICATIONS:

    * Highly useful for blood analysis

    * Biochemistry Measurement in hospital and clinical labs
