Product Details:
Material Borosilicate Glass
Color BLUE
Installation Service Yes
Automatic Water Distillation Equipment (Cabinet Model)
Compact & User Friendly:
This is a fully automatic water distillation equipment and can be used in research laboratories, hospital etc. It is manufacturer from 303 exp borosilicate glass or quartz glass. The distillation has following features:
ü Replaceable Silica Sheathed (Quartz) Heater: The horizontal jacket is fitted with removable silica sheathed heater and screw threaded connectors for ease of cleaning.
ü Distillate temperature is approx. between 25°C to 45°C which is ensured by an efficient condenser.
ü The stand is powder coated for rust free operation and lustrous appearance.
ü Cooling water from the condenser is re-circulated into the boiling chamber, hence saving energy.
ü Screw Threaded Connectors: These are provided for easy plumbing & installation to avoid any glassware breakage during assembly.
ü Fuse is provided for safety in case of voltage fluctuation or short circuit.
ü Boiler is provided with Replaceable Constant Level Device for easy draining and cleaning of boiling chamber.
ü The front cover is easily removable making the access to the glass parts very easy.
ü Electrical Power: 220/240V, 50/60 Hz, Single Phase supply
Technical Specifications:
Borosilicate glass
| Output Cap. (approx) | 2 Ltr/hr | 2 Ltr/hr | 4 Ltr/hr | 4 Ltr/hr |
| Stage | Single Stage | Double Stage | Single Stage | Double Sage |
Distillate Quantity
| Distillate Quantity | Pyrogen Free | Pyrogen Free | Pyrogen Free | Pyrogen Free |
| Conductivity µS/cm | 1.0 – 2.0 | 0.8 – 1.0 | 1.0 – 2.0 | 0.8 -1.0 |
| Cooling water Requirement (approx.) | 1.5 Ltr/min | 2 Ltr/min | 2-3 Ltr/min | 2-4 Ltr/min |
| Power Rating (Total) | 1.5 KW | 3.0 KW | 3.0 KW | 6.0 KW |
** All the parameters are under Standard Test Conditions.
** Output quality would depend upon the quality of inlet feed water
