TECHNICAL SPECIFICATIONS:
MAIN UNIT
- RANGE
- Na: 0 –100 ppm
- K: 0- 100 ppm
- Ca: 15 –100 ppm (Optional)
- Li: 10-100 ppm (Optional)
SENSITIVTY
- Sodium (Na) : 5 ppm
- Potassium (K) : 5 ppm
- Calcium (Ca) : 10 ppm (Optional)
- Lithium (Li) : 10 ppm (Optional)
- READOUT 2½ digit bright red LED display
- ACCURACY + 2% up to 40 ppm, + 5% above 40 ppm
- IGNITION SYSTEM Auto Ignition
- DIMENSIONS 375 X 275 X 220 mm (Approx.)
- WEIGHT 7.5 Kg. (Approx.)
- MEASUREMENT Measures one element at a time
- REPEATABILITY + 2 Counts
- DETECTOR Silicon Photodiode
- FITLER Narrow band interference glass filters
- NEBULIZER Black bakelite, axial flow type
- FLAME SYSTEM LPG & dry oil free air
- WARM UP TIME 10 minutes
- POWER 230V + 10% AC, 50Hz.
COMPRESSOR UNIT (For all Flamephotometer)
- AIR SUPPLY By oil free mini compressor unit with pressure regulator
- COMBUSTION GAS LPG Controlled by precision regulator
- POWER 230V + 10% AC, 50Hz.
- DIMENSIONS 275W X 192H X 240 D mm (Approx.)
- WEIGHT 8Kg. (Approx.)
